RUGGEDCOM

RX1536 Series

6GK6015 - 36-Port Rugged Ethernet Switch and Router

RUGGEDCOM RX1536 Series is a 36-port Rack mount, modular, rugged Ethernet switch and router with enhanced routing, switching and security functionalities

CONFIGURATOR

Model
6GK6015-0DM2 - Mount - S - PM - S1 - S2 - S3 - S4 - MOD	Rugged, modular layer 2 switch + layer 3 router with up to 36-ports 100FX; Up to 36-ports 10/100TX; Up to 8-ports Gigabit Ether-net; Up to 18 ports 10FL/100SX; ST, LC and M12 connector

Mount: Mounting Options
A	No Mounting Option
D	19" rack mounting kit
E	DIN and panel mounting kti

S: Switch Hardware
C	Layer 3 Switch

PM: Power Module
0	No power module 1
1	24 VDC (15-36 VDC) with screw terminal block
2	48 VDC (36-72 VDC) with screw terminal block
3	High voltage (88-300 VDC / 85-264 VAC) with screw terminal block
4	24 VDC (15-36 VDC) with pluggable terminal block
5	48 VDC (36-72 VDC) with pluggable terminal block
6	High voltage (88-300 VDC / 85-264 VAC) with pluggable terminal block
7	12 VDC (9-15 VDC) with screw terminal block
8	12 VDC (9-15 VDC) with pluggable terminal block

Z Options for Software
A01	Layer 3 standard edition (only with Layer 3 hardware)
A03	Layer 3 security edition (only with Layer 3 hardware)

Z Options	S1	S2	S3	S4	S5	S6
Blank module	B00	C00	D00	E00	F00	G00
6 x 10/100BASE-TX RJ45	B01	C01	D01	E01	F01	G01
2 x 10/100/1000BASE-TX RJ45	B02	C02
6 x Serial RS232 / RS422 / RS485 with RJ45	B03	C03	D02	E02	F02	G02
3 x 10BASE-FL / 100BASE-SX, multi-mode, 850 nm, ST, 2 km	B15	C15	D03	E03	F03	G03
4 x 100BASE-FX, multi-mode, 1300 nm, LC, 2 km	B16	C16	D04	E04	F04	G04
4 x 100BASE-FX SFP, blank (no optical transceiver)	B21	C21	D09	E09	F09	G09
4 x 100BASE-FX SFP multimode 1310 nm LC 2km	B22	C22	D10	E10	F10	G10
6 x 100BASE-FX SFP, blank (no optical transceiver)	B26	C26	D14	E14	F14	G14
6 x 100BASE-FX SFP multimode 1310 nm LC 2km	B27	C27	D15	E15	F15	G15
2 x 1000BASE-LX, single-mode, 1300 nm, LC, 10 km	B33	C33
2 x 1000BASE-LX SFP, blank (no optical transceiver)	B36	C36
2 x 1000BASE-SX SFP multimode 850 nm LC 500m	B37	C37
1 x Cellular (GSM/EDGE/HSPA)	B46	C46	D24	E24	F24	G24
1 x Cellular (EVDO rev. A, Verizon USA)	B48	C48	D37	E37	F37	G37
2 x 10/100/1000BASE-TX M12 (8-pin)	B57	C57
4 x 10/100BASE-TX M12 (8-pin)	B58	C58	D36	E36	F36	G36
4 x 10/100BASE-TX M12 (4-pin)	B59	C59	D37	E37	F37	G37
2 x 10/100/1000BASE-TX M12 with controlled bypass (8-pin)	B60	C60
4 x 10/100BASE-TX M12 with controlled bypass (8-pin)	B61	C61	D61	E61	F61	G61
4 x 10/100BASE-TX M12 with controlled bypass (4-pin)	B62	C62	D62	E62	F62	G62
2 x 10/100/1000BASE-TX M12 (8-pin, X-coded)	B63	C63
2 x 10/100/1000BASE-TX M12 with controlled bypass (8-pin, X-coded)	B64	C64
1 x 4G/LTE for usage in European Union (EU)	B65	C65	D65	E65	F65	G65
1 x 4G/LTE for usage in USA & Canada (AT&T/Rogers/Telus/Bell)	B66	C66	D66	E66	F66	G66
1 x 4G/LTE for usage in USA (Verizon)	B67	C67	D67	E67	F67	G67
1 x 4G/LTE for usage in Asia Pacific	B68	C68	D68	E68	F68	G68
2 x APE1808LNX (Atom x5-E3940, 8GB RAM, 64GB eMMC, DisplayPort, uSD , USB, Linux)	B72	C72	D72	E72	F72	G72
2 x APE1808W10 (Atom x5-E3940, 8GB RAM, 64GB eMMC, DisplayPort, uSD, USB, Windows 10)	B73	C73	D73	E73	F73	G73
2 x APE1808ADM (Atom x5-E3940, 8GB RAM, 64GB eMMC, DisplayPort, uSD, USB, CROSSBOW ADM agent software)	B75	C75	D75	E75	F75	C75
1 x 3G/LTE North America (AT&T, Verizon, Rogers, Bell, Telus)	B80	C80	D80	E80	F80	G80

MOD: Manufacturing Modification
0	None
1	Conformal Coating
